CNCGLASS-EVAFORCE-SUPER-Plus-EXTREME-and-EVAVISION-EVA-Film

This catalog presents CNCGLASS EVAFORCE SUPER+ and EVAFORCE EXTREME super clear EVA interlayer films, together with EVAVISION Super Milky White OUTDOOR, Sandblasting White OUTDOOR, Cool Jade White OUTDOOR, and Black Opaque EVA interlayer films for architectural safety laminated glass.

EVAFORCE SUPER+ is described as having the lowest melt viscosity and the best compatibility with uneven or rough-surface inserts. It is intended for high-volume lamination and for both indoor and outdoor use. EVAFORCE EXTREME is described as having less overflow during vacuum heating and enhanced safety mechanical properties. It is recommended for extreme environments, safety tempered glazing, or curved-glass laminating, and is also suitable for indoor and outdoor applications. Standard roll sizes listed for both super clear grades are 0.38 mm × 2300 mm × 100 m, 0.76 mm × 2300 mm × 50 m, and 1.14 mm × 2300 mm × 30 m; other widths are available.

The EVAVISION outdoor white grades are listed at a curing temperature of 125°C: Super Milky White OUTDOOR for high privacy and a purer white color, Sandblasting White OUTDOOR as a translucent grade for medium privacy, and Cool Jade White OUTDOOR for medium privacy in exterior and interior applications. Black Opaque (EVAVISION BO) is listed at a curing temperature of 115°C for high privacy. The standard size listed for these colored films is 0.38 mm × 2000 mm × 50 m; other widths are available.

Laboratory data in the catalog for both super clear grades include light transmittance of at least 91.0% (390 nm–900 nm), haze of at most 0.25%, and recommended vacuum-oven lamination cycles. This catalog does not list prices. Enquiries can be sent to cnc@cncglass.com. The full catalog is in the PDF below.

CNCGLASS-Transparent-White-EVA-Laminated-Glass-Heat-and-Humidity

This technical note covers a transparent white decorative EVA laminate from CNCGLASS: two 3.9 mm clear float plies bonded with a 0.38 mm transparent white decorative EVA interlayer, at a nominal thickness of 8.2 mm. High-temperature resistance (Procedure A, 16 h) and humidity resistance with condensation were evaluated to EN ISO 12543-4:2011. None of the six specimen results showed bubbles, delamination or cloudiness, and both items conformed. The evaluation covers heat and humidity only, not colour shift under ultraviolet exposure. The document is a CNCGLASS performance summary, not a third-party test certificate or certificate of conformity. This technical note does not list prices. Enquiries can be sent to cnc@cncglass.com. The full note is in the PDF below.
