Is it a total nightmare to fix edge bubbles when you’re laminating glass with fine silk fabric?

One of our clients was running into exactly that problem. They were processing super-thin, lightweight silk fabric EVA laminated glass, and every single piece came out with bubbles right along the edges. Even the glue that squeezed out looked all foamy and bubbly.

To figure out what was really going on, we ran three full rounds of experiments in our lab. In the end we nailed down the biggest traps people fall into when working with these delicate fabrics—so stick around till the very end, you’re gonna want these tips.

Round 1 – Copying the client’s exact process

We followed their recipe to the letter: hold at 60 °C for 20 minutes, then 125 °C for 60 minutes. Our lab furnace ran the exact same cycle, and guess what? Same edge bubbles showed up. So we ruled out their equipment being the culprit and decided to tweak the parameters instead.

Round 2 – Slow it down and cool it down

We lowered the temperatures and slowed the ramp rate:

– 60 °C for 20 minutes

– 80 °C for 20 minutes

– 105 °C for 60 minutes

– Ramp rate of just 4 °C per minute

Boom—after this new cycle, the lab samples came out with perfectly clean edges, zero bubbles. We sent the updated process to the client. They ran a new batch and… the bubbles got way better, but they still weren’t completely gone.

So why did the same recipe work perfectly in our furnace but not in theirs? Simple: every laminating machine is different. Heating speed, temperature sensors, temperature control, even the internal layout—all of that changes the final result. Glass made on one machine just isn’t the same as glass made on another.

Round 3 – The knockout punch

To finally solve it for good, we went deeper. First we tested the fabric itself and discovered the shrinkage rate was a crazy 3–4 % and the moisture content was way too high. So before laminating, we pre-dried the silk fabric to let it shrink ahead of time and drop the moisture level. On top of that we switched to our low-flow EVA film—EVAFORCE EXTREME.

That one-two-three combo was magic. When the client ran the new process in their own factory… edge bubbles? Completely gone.

Our practical advice for anyone working with fine silk fabric, lightweight cloth, loose weaves, or natural fibers

These materials have pretty low structural stability, so you’ve got to pay extra attention before you laminate:

1. Store the fabric in a constant temperature and humidity room so it doesn’t pick up extra moisture.

2. Pre-dry and pre-shrink the fabric to reduce the shrinkage that happens during the actual lamination cycle.

3. Control your laminating furnace’s ramp rate—don’t let the temperature overshoot and make sure the glass heats up evenly inside the chamber.

4. Use a low-flow EVA film (like our EVAFORCE EXTREME) to keep the melted glue from pushing and deforming the fabric too much.
