CNCGLASS-White-EVA-Interlayer-Film-Privacy-Performance-Technical-Note

This technical note presents the privacy performance of the CNCGLASS white EVA interlayer film series for architectural laminated glass. The series comprises three white translucent-to-opaque grades — Super Milky White, Sandblasting White and Cool Jade White — which, laminated between two plies of glass, produce privacy glazing with progressively different degrees of light transmission and visual screening. All data in the note are based on the reference laminate construction 4 mm glass + 0.38 mm EVA film + 4 mm glass.

Privacy performance is graded on a ten-point scale: low privacy (0–3) when objects behind the glass are clearly visible, medium privacy (4–6) when the view is partially obscured, and high privacy (7–10) when only vague shadows and colours can be discerned. In the reference construction, all three grades achieve a High Privacy rating, with light transmittance of ≤ 1% / ≤ 5% / ≤ 25% and haze of ≥ 97% / ≥ 95% / ≥ 90% for Super Milky White, Sandblasting White and Cool Jade White respectively. Super Milky White is described as effectively opaque and suited to spandrel panels, partitions and applications where no vision is wanted; Sandblasting White reproduces the visual effect of sandblasted glass with the diffusing medium sealed inside the laminate; Cool Jade White transmits a soft, jade-like diffuse glow while still screening detail. Because the white diffusing layer is encapsulated within the laminated construction, the note states that the privacy effect is permanent and the panel retains the safety and structural behaviour of laminated glass.

The document is a CNCGLASS technical note and performance summary. It is not a third-party test certificate or a certificate of conformity, and it does not authorise the use of any third-party laboratory mark. This technical note does not list prices. Enquiries can be sent to cnc@cncglass.com. The full note is in the PDF below.

CNCGLASS-Ionoplast-Interlayer-Laminating-Process-Guide

This processing guide gives glass fabricators recommended starting practice for laminating architectural and structural glazing with the CNCGLASS ionoplast interlayer, a stiff ionic-type film intended for high structural performance and reliable post-breakage retention. Conventional PVB laminating equipment can generally be used; the temperatures, pressures and times in the note are starting points that should be validated and fine-tuned on each production line.

The note covers packaging and storage of foil-bagged rolls (use within two years of production; material above 0.2% moisture should not be used; recommended lay-up conditions are 22–28 °C and 18–28% RH), cutting and trimming without sawing, cleaning, and glass preparation with the interlayer laid against the tin sides in the ATTA orientation. It then describes nip-roll pre-pressing and vacuum-bag de-airing, followed by an autoclave hold of 132–135 °C at 180–200 psi for at least 60 minutes and a cooling rate of at least 3 °C/min. Further sections address multi-ply stacks, when an adhesion promoter is required, coated and fritted glass, daily quality checks, and a troubleshooting table for low adhesion, trapped air, rainbow distortion and high haze.

The document is a CNCGLASS technical note and processing guide. It is not a third-party test certificate or a certificate of conformity, and it does not authorise the use of any third-party laboratory mark. This technical note does not list prices. Enquiries can be sent to cnc@cncglass.com. The full guide is in the PDF below.
